BODY
16
NOTE
Check the condition of the rubber grommet, if
found damaged replace the same at the time
fitment.
III. HOOD LATCH ASSEMBLY
REMOVAL
1. Disconnect the hood release cable from the
hood latch assembly.
(For procedure refer
Bonnet latch release cable removal process.)
2. Loosen and remove three mounting bolts and
lower the hood latch assembly and separate it
from the vehicle.
FITMENT
For fitment follow the reverse procedure of
removal.
IV.
HOOD LATCH (BONNET SIDE)
REMOVAL
1. Open the bonnet.
2. Loosen and remove two mounting bolts and
take out the hood latch from bonnet end.
FITMENT
For fitment follow the reverse procedure of
removal.
V.
BONNET INSULATION:
REMOVAL:
1. Open the bonnet.
2. Pull out the insulation from the bonnet
assembly.
FITMENT:
For fitment follow reverse procedure of removal.
NOTE:
Check the condition of clips if found damaged
replace the same with the new one.
