1753 / 1906
BODY
18
8. Remove ETC bezel from the front cover.
9. Remove the ESP bezel from the front cover.
10. Remove the two screws from boot end of floor
console assembly.
11. Remove the floor console assembly cap cover
and screw below cap cover.
12. Take out the rear cap at the back and remove
mounting screws of floor console. Follow the
same procedure on other end.
