HEXA

BODY

B. FLOOR CONSOLE

REMOVAL:

1. Pull out the rubber boot from the floor console.

2. Loosen the locking nut.

3. Remove the gear lever knob.

4. Remove the gear lever boot using popper tool

set.

5. Remove the all electrical connection of PNRD

module.

6. Loose and remove the mounting screw of front

cover with ETC and ESP bezel.

7. Remove the front cover with ETC and ESP

bezel.
