ELECTRICAL
135
BCM SPECIFICATION:
1
Operating voltage range
8.5 V to 15.5 V DC
6.5 V to 15.5 V DC (for Hazard Functionality)
2
Operating temp range
- 30
c to +85
c
3
Storage temp range
- 40
c to +105
c
4
Quiescent current (No function Active)
less than 1.5mA
4a
Transport mode
less than 0.4mA
5
BCM connector type (Header)
No header; it’s part of the BCM housing itself
6
BCM connector type (Mating)
Tyco make
7
Vehicle mounting location
Below dash board and above glove box with metallic
bracket
8
Mounting orientation
Horizontal with connectors downwards – 45 degree
angular from horizontal plane
9
Remote operating voltage
8.5 V to 15.5 V DC
10
Standard for hazardous material
2000/53/EC
11
Diagnostics
OBD on CAN
12
Tolerances
Tolerances on timing +/- 10% unless and otherwise
specified
