760 / 1002
ELECTRICAL
139
CONNECTOR B: MATING SIDE HARNESS 25 PINS CONNECTOR CON 2
PIN
NO
SIGNAL NAME
USED
SIGNAL
TYPE
ACTIVE
LEVEL
SIGNAL
DESTIN-
ATION
LOAD
TYPE/
INPUT TYPE
1
Reverence Lamp Signal Right
Y
Digital
High
Output
Bulb/LED
2
-
-
-
-
-
-
3
Front Roof Lamp Control
Y
PWM
High
Output
Bulb
4
ACC Delay Control
Y
Digital
High
Output
-
5
-
-
-
-
-
-
6
Position Lamp Control Left
Y
Digital
High
Output
Bulb/LED
7
Wash Front Pump Ctrl
Y
Digital
High
Output
Motor
8
Turn Left Indicator
Y
Digital
High
Output
Bulb/LED
9
Brake Lamp Signal Left
Y
Digital
High
Output
Bulb/LED
10
Fog Lamp Control Front Left
Y
PWM
High
Output
Bulb
11
Reverence Lamp Signal Left
Y
Digital
High
Output
Bulb/LED
12
Door Pocket LED Out
Y
PWM
High
Output
LED
13
Foot well LED Out
Y
PWM
High
Output
LED
14
Brake Lamp Signal Right
Y
Digital
High
Output
Bulb/LED
15
Turn Right Indicator
Y
Digital
High
Output
Bulb
16
Wash Rear Pump Control
Y
Digital
High
Output
Motor
17
Position Lamp Control Right
Y
Digital
High
Output
Bulb/LED
18
Battery Saver Control
Y
Digital
High
Output
-
19
Fog Lamp Control Front Right
Y
PWM
High
Output
Bulb
20
-
-
-
-
-
-
21
-
-
-
-
-
-
22
-
-
-
-
-
-
23
-
-
-
-
-
-
24
-
-
-
-
-
-
