Wash Front Switch Signal
Y
Digital
Low
Input
-
25
Wiper Front Switch Signal
Intermittent
Y
Digital
Low
Input
-
26
Crash Signal HW
Y
Digital
High
Input
-
27
Door Unlock Control Driver
Y
Digital
Low
Output
Ext. Relay
28
Hazard Switch LED Signal
Y
PWM
High
Output
LED
29
Door Lock Control All
Y
Digital
Low
Output
Ext. Relay
30
Horn Signal
Y
Digital
Low
Output
Ext. Relay
31
Head Lamp Low Beam Relay
Y
Digital
High
Output
Ext. Relay
32
-
-
-
-
-
-
33
Internal GND1
Y
GND
Low
Ground
-
34
Battery GND1
Y
GND
-
Ground
-
35
-
-
-
-
-
-
36
Wiper Front Speed Switch Signal
Y
Analog
-
Input
-
37
Fog Lamp Front Switch Signal
Y
Digital
Config
Input
-
38
Ambient Light Switch Signal
Y
Digital
Low
Input
-
39
Reverse Gear Signal
Y
Digital
High
Input
-
40
Wiper Front On Off Relay
Control
Y
Digital
Low
Output
Ext. Relay
41
Wiper Rear Relay Control
Y
Digital
Low
Output
Ext. Relay
42
Door Unlock Control Others
Y
Digital
Low
Output
Ext. Relay
43
Wake Up Input
Y
Digital
High
Output
Signal
44
Front Fog Lamp Relay
Y
Digital
Low
Output
Ext. Relay
45
Rear Defogger Relay Control
Y
Digital
High
Output
Ext. Relay
46
Internal_12V
Y
Digital
High
Output
-
47
Battery GND2
Y
GND
-
Ground
-
48
CAN Chassis H
Y
CAN
-
Bus
-
49
CAN Chassis L
Y
CAN
-
Bus
-
