757 / 1002
ELECTRICAL
136
8.25.1 BCM CONNECTOR PIN SIGNALS APPLICABILITY MATRIX:
CONNECTOR A: MATING SIDE HARNESS 52 PINS CONNECTOR CON 1-BLACK
PIN
NO
SIGNAL NAME
USED
SIGNA
L TYPE
ACTIVE
LEVEL
SIGNAL
DESTIN-
ATION
LOAD TYPE/
INPUT TYPE
1
Driver Door State
Y
Digital
Low
Input
WKUP I/P
2
Transport Link Signal
Y
Digital
High
Input
-
3
Door Latch Set Switch Signal
Driver
Y
Digital
Low
Input
WKUP I/P
4
Head Lamp ON Signal
Y
Digital
Low
Input
WKUP I/P
5
Wiper Rear park Signal
Y
Digital
Low
Input
-
6
Engine Start Stop Switch Signal
Y
Digital
Config.
Input
-
7
Turn Right Switch Signal
Y
Digital
Low
Input
-
8
Driver Door Unlock Signal
Y
Digital
Low
Input
WKUP I/P
9
Ignition Key State IGN
Y
Digital
High
Input
WKUP I/P
10
Key IN Signal
Y
Digital
High
Input
WKUP I/P
11
Infotainment Removal Detection
Y
Analog
-
Input
WKUP I/P
12
Wash Rear Switch Signal
Y
Digital
Low
Input
-
13
Wiper Rear Mode Switch Signal
Y
Digital
Low
Input
-
14
Co-driver/Other Door State
Y
Digital
Low
Input
WKUP I/P
15
Position Lamp Switch Signal
Y
Digital
Low
Input
WKUP I/P
16
Door Latch Reset Switch Signal
Driver
Y
Digital
Low
Input
WKUP I/P
17
Spare1
Y
Digital
High
Input
-
18
Wiper Front Park Signal
Y
Digital
Low
Input
-
19
Turn Left Switch Signal
Y
Digital
Low
Input
-
20
Driver Door Lock Signal
Y
Digital
Low
Input
WKUP I/P
21
Ignition Key State CRANK
Y
Digital
High
Input
-
22
Brake Light Switch Signal
Y
Digital
High
Input
WKUP I/P
23
Ignition Key State ACC
Y
Digital
High
Input
WKUP I/P
