CONNECTOR C: MATING SIDE HARNESS 2 PINS CONNECTOR CON 3
PIN
NO
SIGNAL NAME
USED
SIGNAL
TYPE
ACTIVE
LEVEL
SIGNAL
DESTIN-
ATION
LOAD
TYPE/
INPUT TYPE
1
Power Supply 2
Y
BATT
-
+VCC
-
2
Power Supply 1
Y
BATT
-
+VCC
-
CONNECTOR D: MATING SIDE HARNESS 52 PINS CONNECTOR CON 4-BLUE
PIN
NO
SIGNAL NAME
USED
SIGNAL
TYPE
ACTIVE
LEVEL
SIGNAL
DESTIN-
ATION
LOAD
TYPE/
INPUT TYPE
1
Wiper Front Low High Relay
Control
Y
Digital
Low
Output
Ext. Relay
2
Global Closing Signal
Y
PWM
High
Output
Signal
3
Cent Lock Internal Switch Signal
Y
Digital
Low
Input
WKUP I/P
4
Bonnet State
Y
Digital
Low
Input
WKUP I/P
5
Rear Right Door State
Y
Digital
Low
Input
WKUP I/P
6
Low Beam Switch Signal
Y
Digital
Low
Input
WKUP I/P
7
Wiper Front Low Speed Signal
Y
Digital
Low
Input
-
8
Mirror Fold Unfold Switch
Y
Digital
Low
Input
-
9
Smart Entry Wakeup Signal
Y
Digital
High
Input
WKUP I/P
10
Spare3
Y
Digital
Low
Input
-
11
Auto Light ON Signal
Y
Analog
-
Input
-
12
-
-
-
-
-
-
13
-
-
-
-
-
-
14
Key Hole LED Control
Y
PWM
High
Output
LED
15
Tailgate State
Y
Digital
Low
Input
WKUP I/P
16
Cent Unlock Internal Switch
Signal
Y
Digital
Low
Input
WKUP I/P
17
Rear Left Door State
Y
Digital
Low
Input
WKUP I/P
