1.05L REVOTORQ ENGINE
50
iii. AIR FILTER ELEMENT REPLACEMENT :
Description :
Proper maintenance of the air filter is
essential for vehicle performance and fuel
economy. The air filter element removes
foreign material such as dust, dirt, and
other material from the intake air, thereby
preventing the engine from damage due to
contaminated air.
Inspect and clean the air filter element at
every routine service. Replace the air filter
element every 45,000 km or 36 months.
Removal :
1. Park the vehicle on a level surface, engage
the parking brake, and raise the hood.
2. Unscrew the top Two mounting bolts of air
filter assembly & one locator point at back
side.
3. Detach the cover through hinge action, with
clamp and snorkel intact with cover.
4. Remove the air filter element.
5. Gently tap loose any dirt or debris from the
filter. Clean the housing and air ducts as
well. Take care not to allow dirt and debris
to enter the air inlet to the engine.
Inspection :
1. Hold the air filter element up to a light
source. Light should be visible through the
element. There should be no holes or tears
in the element.
2. The filter can also be cleaned using low
pressure compressed air.
3. Replace the filter element if torn or light is
not visible through the filter.
Installation :
1. Place the air filter element.
2. For re-assembling the cover, please ensure
that all the hinge lugs are properly assembled
in the slot of the air filter housing body, before
tightening the screws.
