TRANSAXLE (NANO AMT)
102
10. Fit the ball bearings on both ends using Tool
no. 2834 5890 26 05 DRIFT FOR FITMENT
OF DIFFERENTIAL BEARING, Make sure
that the stamped side should project upwards.
11. TOPCOVER ASSEMBLY:
A. DISMANTLING:
1. Remove the AMT kit. For procedure refer
“AMT KIT removal”.
2. Remove the table spiral pin.
CAUTION:
A Special care should be taken while
dismantling the table spiral pin to avoid interface
finger and selection spring coming outside
forcefully and leading to an accident.
3. Remove the interface finger.
4. Remove the selection spring.
