TRANSAXLE (NANO AMT)
98
9. REVERSE GEAR SHIFTER BRACKET –
ASSEMBLY:
1. Place the barrel with spring onto the reverse
idler shaft bracket.
2. Place the ball on the spring.
3. Place the reverse lever such that the groove
meshes with the detent.
4. Insert the pin and tighten the M8 nut to a torque
of 2.1 ~ 2.5 kgm.
