TRANSAXLE (NANO AMT)
105
12. REAR HALF HOUSINGASSEMBLY:
A. DISMANTLING:
1. Remove the oil channel.
2. Remove the select shaft shifter needle
bearing.
3. Remove the dowel pins from the top cover
housing in the rear half housing.
B. ASSEMBLY:
1. Fit the selector shifter shaft needle bearing on
the rear half and tap it to place using a suitable
drift.
2. Tighten the magnetic drain plug to a torque of
3.5 Kg m.
3. Fit the Drive shaft seal to the rear half using a
suitable drift.
