BODY
42
9.10.3 Removal and Refitment of Front Door
Trims, Window Regulator, Latch and Door
Handle:
Removal:
1. Pull out the inside cover plate rubber boot of
the ORVM.
2. Remove Inside cover plate using plastic.
3. Unscrew the 2 mounting screws by screw
driver.
4. Remove the door release lever holding
screws, as shown in fig. Insert wedge pin and
pry out.
5. Disconnect the two linkages (lock and unlock)
of the door release lever and remove it.
6. Insert wedge pin and remove window-winding
switch from door pull outer.
