BODY
50
15. Remove the latch after unscrewing the
screws.
16. Remove the glass divisional channel holding
bolt.
17. Pull out the quarter glass after removing the
divisional channel.
18. Unscrew and remove the door outer rub rail.
19. Raise the window glass to half the height.
20. a) Remove the two 2 mounting screws from
the glass holding bracket. (If applicable)
b) Remove the glass after prying out the lock
over it.
21. Unscrew and remove 2 upper mounting bolts
and one lower bolt of the glass mechanism
channel.
