ENGINE 1.3L QUADRAJET (90PS)
50
NOTE :
Replace the copper washers on the connectors.
NOTE :
Follow the order shown in the figure for each
tightening sequence. The tightening to 0.8 - 1.0
Kg-m is performed in two stages: pre tightening
to 0.4 Kg-m followed by an additional tightening
of 0.8 - 1.0 Kg-m
65.
Position a new gasket between the crankcase and
the engine oil return pipe to the turbocharger.
66.Tighten the M6 bolts securing the engine oil return
pipe from the turbocharger, crankcase side, to a
torque of 0.8 ~ 1.0 kg-m.
67.Fit the protective strips to the oil filter and the engine
oil heat exchanger.
68.Place the electrical wiring in position and fasten it
to the bands on the air capacity chamber.
69.Connect the electrical connection to the E.G.R.
solenoid valve.
70.Connect the electrical connection to the fuel
pressure regulator.
71.Secure the electrical connection for the pressure
relief sensor.
72.Connect the electrical connection to the fuel
pressure sensor.
73.Refit the electrical wiring in its seat and secure.
74.Tighten the bolts securing the wiring duct to the
cylinder head.
75.Connect the electrical connection for the air
conditioning compressor engagement solenoid
valve.
76.Connect the electrical connection to the timing
sensor.
77.Secure the electrical connections to the injectors.
78.Secure the electrical connections to the heater
plugs.
79.Connect the electrical connection to the engine oil
pressure warning light switch.
80.Connect the electrical connection for the engine
rpm sensor.
81.Secure the electrical connection to the engine
coolant temperature sensor.
82.Connect the electrical connection for the
(pneumatic) throttle control solenoid valve
83.Remove the engine from the overhaul stand.
