39 / 801
HV ELECTRICAL SYSTEM
31
8. Remove drive shaft by pulling disk brake and
Take out drive shaft LH / RH from gearbox.
(Drain oil before carrying out this process).
9. Loosen and Remove the mounting screw and
take out the motor cover.
10. Remove the connector and cable of motor
controller connected to PDU.
11. Disconnection the wiring harness of motor.
12. Remove of ground cables of E-drive.
13. Remove the Hose Pipe Charger out to Motor
Inlet and drain coolant.
