HV ELECTRICAL SYSTEM
32
14. Loosen and remove the mounting bolts of
motor bracket support.
15. Loosen and remove the mounting bolts of
motor bracket support.
16. Loosen and remove the mounting bolts of
upper side motor bracket support.
17. Loosen and remove the mounting bolt of sub
frame bottom shell.
18. Loosen and remove the mounting bolt nuts of
Bracket C-Mount.
19. Use special tool to keep E drive safely down
take it out.
Fitment
Follow reverse procedure for assembly.
