KRYOTEC ENGINE
114
21. Disconnect the glow plug wire harness
connector (1) from each glow plug.
22. Disconnect the fuel pressure sensor wire
harness connector (2).
23. Remove the bolt (3) securing the wire harness
assembly to the intake manifold and position aside.
24. Disconnect the pressure sensor wire harness
connector (4).
25. Remove the bolts (1a) securing the oil vapor
pipe (1b) and position aside.
26. Remove the bolt (1) securing the wire harness
to the intake manifold.
27. Remove the bolt (2) and the intake manifold
support bracket.
28. Remove the bottom mounting stud (1) securing
the fuel injection pump.
29. Remove the intake manifold mounting nuts (1).
