KRYOTEC ENGINE
113
14. Remove the EGR valve and manifold (Refer to
25 - Emissions Control/Exhaust Gas Recirculation,
Diesel/ VALVE, Exhaust Gas Recirculation
(EGR)/Removal and Installation).
15. Remove the clamp and the oil vapor pipe (1).
16. Remove the bolt (2) securing the oil vapor
separator to the intake manifold.
17. Remove the lower bolt (1) securing the engine
oil vapor recovery pipe to the engine block.
18. Disconnect the swirl valve actuator wire
harness connector (2).
19. Remove the bolt (1) securing the oil recovery
pipe to the oil pan.
20. Remove the oil vapor separator assembly
complete with O-ring.
