KRYOTEC ENGINE
119
minutes.
Note: Do not shut down engine till the warning lamp
goes OFF.
If DPF regeneration process requested above is not
followed for a long distance and the vehicle is
driven with warning lamp ON, it can cause MIL to
be turned ON.
Once MIL is ON, the please contact TML Service.
Service should connect the TML diagnostic tool and
conduct DPF service regeneration as indicated in
the diagnostic tool.
Insufficient DPF regeneration resulting in the above
lamps can also happen if the vehicle is driven with
adulterated diesel.
!! WARNING
PARKING WARNING
Avoid parking of vehicle over inflammable
materials, such as dry leaves; grass etc. as exhaust
system is hot enough to initiate fire.
! CAUTION
Ensure exhaust system and assembly DOC+DPF
is not blocked and is free from obstruction.
•
Blockages in the exhaust can create back
pressure, low top speed, poor pick up, black
smoke, carbon build up and low mileage.
•
Check and ensure EGR Valve & control system
is clean and functioning properly.
•
Excessive carbon build-up / sticky valve.
• Damaged vacuum lines.
All these can keep the ‘EGR’ open when not
desired and vice versa. Either way these can
seriously affect power output of the engine and also
the emission levels.
! CAUTION
The assembly DOC+DPF should not be dropped
from a height. If dropped, it should not be used.
AdBlue (DIESEL EXHAUST FLUID (DEF))
The vehicle is equipped with an AdBlue Diesel
Exhaust Fluid (DEF) injection system and SCR to
meet emission standards. These two systems
ensure compliance with the diesel emissions
requirements; at the same time they ensure fuel-
efficiency, handling, torque and power. For
messages and system warnings, refer to the
“warning lights and messages”. AdBlue (Diesel
Exhaust Fluid (DEF)) is a very stable product with
a long shelf life. Stored at temperature lower than
90
°
F (32
°
C) has a shelf life of at least one year.
The vehicle is equipped with an automatic AdBlue
(Diesel Exhaust Fluid (DEF)) heating system when
the engine starts allowing the system to work
correctly at temperature lower than 12
°
F (-11
°
C).
AdBlue (Diesel Exhaust Fluid (DEF)) Storage
AdBlue (Diesel Exhaust Fluid (DEF)) is considered
a very stable product with a long shelf life. If AdBlue
is kept in temperatures between 10
°
and 90
°
F (-
12
°
and 32
°
C), it will last a minimum of one year.
AdBlue (Diesel Exhaust Fluid (DEF)) is subject to
freezing at the lowest temperature. For example,
AdBlue (Diesel Exhaust Fluid (DEF)) may freeze at
temperatures at or below 12
°
F (-11
°
C). The system
has been designed to operate in this environment.
NOTE
When working with AdBlue (Diesel Exhaust Fluid
(DEF)), it is important to know that
Any containers or parts that come into contact
with AdBlue (Diesel Exhaust Fluid (DEF)) must
be AdBlue compatible (plastic or stainless
steel). Copper, brass, aluminum, iron or non-
stainless steel should be avoided as they are
susceptible to corrosion by AdBlue (Diesel
Exhaust Fluid (DEF)).
If AdBlue (Diesel Exhaust Fluid (DEF)) is
spilled, it should be wiped up completely.
Adding AdBlue (Diesel Exhaust Fluid (DEF))
Consumption of the additive (Diesel Exhaust Fluid
(DEF)) depends on the condition of vehicle use and
is indicated by the LED and / or the message on the
instrument panel.
AdBlue (Diesel Exhaust Fluid (DEF)) freezes freeze
at temperatures at or below 12
°
F (-11
°
C). If the car
stands for a long time at this temperature refilling
could be difficult. For this reason, it is advised to
park the vehicle in a garage and / or heated
environment and wait for the Diesel Exhaust Fluid
(DEF) to return to liquid state before topping up.
Proceed as follows:
Park the car on flat ground and stop the engine by
placing the ignition in the OFF position.
Open the fuel door, undo and remove the cap (blue)
from the AdBlue (Diesel Exhaust Fluid (DEF)) filler.
CAUTION
Never fill AdBlue (Diesel Exhaust Fluid (DEF)) or
diesel fuel into the wrong filling ports. This may
result in serious damage to Engine, fuel system and
emission system components. Incase of wrongly
filled do not start the engine, contact the authorized
dealer.
