1.2L REVOTRON ENGINE
119
6. Remove the Oil Sump along with the sealant
by using sealant cutting wedge.
7. Remove the mounting fasteners of lube oil
strainer and o-ring.
IV. Removal of Sensors
1. Remove Cam Phase Angle Sensor from both
sides.
2. Remove Crank Angle/RPM Sensor from the
Engine Block.
