1.2L REVOTRON ENGINE
115
8. Remove the Fuel Rail along with the injectors.
9. Remove the injector retainer on the fuel rail.
10.Remove the fuel injectors.
NOTE
Injector should be tagged as soon as it is
removed to avoid chances of it being
interchanged. Since the code of each
injector is calibrated to the EMS, whenever
an injector is replaced it codes of the
respective injectors should be fed in the
EMS ECU using diagnostic tool.
11. Loosen and remove the mounting bolts of the
bottom support bracket to the intake manifold.
12. Removing the fasteners to take out the Intake
Manifold
