1.2L REVOTRON ENGINE
122
11. Remove the mounting bolts to take out the oil
filter holder.
12. Remove the mounting bolts and locating pin
to unmount the clutch cover assembly.
13. Remove the crankshaft pulley.
NOTE
Ensure the flywheel in lock position during
crankshaft pulley removal as given below.
14. Loosen and remove the mounting bolt of the
EVRV support bracket and take out the
assembly along with the EVRV unit.
15. Remove the vacuum pump assembly by
removing its mounting bolts.
