1.2L REVOTRON ENGINE
112
5. Note down the temperature when dial gauge
needles starts moving indicating valve
opening.
6. Note down the water temperature for needle
movement
(for valve fully open position).
7. The opening temperature and fully open
temperature as measured should be as per the
mentioned specifications.
If they do not meet the specifications, replace the
thermostat element.
H. REMOVAL OF ACCESSORIES
1. Rotate the tensioner point by using ring
spanner opposite to belt tension to loosen the
belt.
2. Remove the belt.
3. Remove the alternator mounting bolts and
take it out along with the bracket.
