1.2L REVOTRON ENGINE
107
G. COOLING SYSTEM
COOLANT TANK REMOVAL
1. Drain the coolant,
(For procedure refer
“Coolant Replacement” in Engine maintenance
section)
2. Disconnect the vent tubes between radiator
and cylinder head connecting to the auxiliary
water tank
.
3. Loosen and remove the tanks mounting bolts.
4. Lift the coolant tank and disconnect the hose
clamp to remove the hose connecting auxiliary
tank to water bypass and take out the coolant
tank.
FITMENT
For fitment follow the reverse order of removal.
