BODY
21
2.9 REAR BUMPER
REMOVAL
1. Open the tail gate.
2. Remove the 2 Nos. of Mounting screws M8
special screw.
3. Remove rear Lamp (For procedure refer Rear
Lamp removal process in Electrical section.)
4. Loosen and remove the bumper clip below
rear lamp LH \ RH side.
5. Loosen and remove all rear bumper six clip
which hold the rear bumper from bottom side.
6. Loosen and remove screws which are inside
the wheel arch LH & RH.
7. Take care that the tailgate seal is removed for
easy removal of bumper.
