BODY
20
2.8 FRONT BUMPER
REMOVAL
1. Open the bonnet.
2. Remove the 2 Nos. of Mounting screws M8.
3. Remove 4 clip buttons from the bumper skin.
4. Loosen and remove the mounting screws
along with the washers from the bottom side of
the bumper.
5. Loosen and remove two mounting screws of
the outer liner from the inner side of wheel
arch. Follow the same procedure at the other
end also.
6. Pull out the front bumper from wheel arch end.
7. Disconnect fog lamp connectors and remove
the bumper.
FITMENT
For fitment follow the reverse procedure of
removal.
