BODY
23
FITMENT
For fitment follow the reverse procedure of
removal.
NOTE
a) For fitment bolts (Self aligning bolt) shown as
1
st
to be fasten first & then bolt shown as
2
nd
b) “For Side door Rattling Noise, Door Latch and
striker setting need to be done & maintain 1
mm under flush condition.”
2.11 FRONT DOOR TRIMS
REMOVAL
1. Open the Door.
2. Remove window-winding switch from door pull
outer.
3. Disconnect the window winding connection
and remove the switch.
4. Remove the mounting screw and clip and pull
out the arm rest.
5.
Loosen and remove the mounting screw of
inner handle.
