BODY
14
2.5 COCKPIT REMOVAL ( COMPLETE ASSY)
REMOVAL
1. Remove Door (For procedure refer Door
removal process in Door section.)
2. Remove the end covers from both sides.
3. Pull out the mounting Cap.
4. Remove two dashboard mounting bolts on LH
/ RH side as shown in figure.
5. Remove steering wheel with Driver air bag (if
applicable) (For procedure refer steering
wheel removal process in steering section.)
6.
Removal of 2 firewall mountings
.
7. Remove 2 mountings and remove the tunnel
link assembly.
8. Remove mounting screws & Pull out the
driver side steering lower panel.
9. Remove mounting screws at steering column.
