BODY
11
5. Remove screw at glow box location and pay
out glow box.
6. Remove mounting screw and pull out the
center lower panel.
7. Remove mounting screw of control module.
8. Remove combination switch assembly and
ignition switch assembly (For procedure refers
combination switch and ignition switch
removal process in Electrical section.)
9. Pull Out the bezel cover and disconnect the
peps start stop switch.
10. Pull out the instrument cluster hood.
11. Remove the mounting screw of instrument
cluster cover. (For procedure refer instrument
cluster removal process in Electrical section.)
12. Remove instrument cluster. (For procedure
refer instrument cluster removal process in
Electrical section.)
