20. Remove A pillar Lower trim. (For procedure
refer A pillar trim removal process.)
21. Pull out the front panel.
22. Remove two mounting screw near A
pillar.(LH,RH)
23. Remove mounting screw and nut of
dashboard.
24. Disengage 4 locators located on BIW plenum
panel brackets.
25.Remove the dashboard, while removing
Dashboard carefully disengage HVAC system
behind the glove box.
FITMENT
For fitment follow reverse procedure of the
removal.
