HARRIER BOOK 2

Q501 4 Cylinder MT Application

DTC Troubleshooting Data

Version: 0.1

Date: 21-Sep-2018

Prepared By: Mithi Prasad, Sarang Kulkarni, Manish Gupta

Checked By: Yogesh Jadhav

Approved By: Satish Kumar P

Page: 1045 of 1052

TATA MOTORS Ltd.

This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.

124

P0194-84

Fuel Rail Pressure Sensor "A" Circuit Intermittent/Erratic :

Negative offset of the rail pressure sensor exceeded

368

125

P0194-85

Fuel Rail Pressure Sensor "A" Circuit Intermittent/Erratic :

Positive offset of the rail pressure sensor exceeded

372

126

P0641 – 1C Sensor supply 1 - voltage out of range

376

127

P0697 – 1C Sensor supply 3 - voltage out of range

381

128

P1D55-96

Serial Peripheral Interface communication (component

internal failure)

384

129

P1D56-04 Serial Peripheral Interface communication (system internal failures)

386

130

P1D57-64 Serial Peripheral Interface communication (signal plausibility failure)

388

131

P1D58-49 Serial Peripheral Interface communication (internal electronic failure)

390

132

P26E4-13 Open Load Error at Starter Low side power stage

392

133

P26E5-11 Short circuit to ground at Starter Low side powerstage

395

134

P26E6-12 Short circuit to battery at Starter Low side power stage

398

135

P0615-13 Open Load Error at Starter High side power stage - Circuit Open

401

136

P0616-11 Short circuit to ground Error at Starter High side power stage

404

137

P0617-12 Short circuit to battery Error at Starter High side power stage

407

138

P1277-14 Plausibility check Vsensing short to gound or open circuit during crank

410

139

P1278-64 Plausibility check R1 and R2 stuck closed or short circuit to battery Vsensing at Ignition ON

413

140

P06E9-71

Engine Starter Performance :Engine Starter

Performance:Starter Stalled fault

416

141

P26F1-73 Starter Relay1 stuck closed

419

142

P26F3-73 Starter Relay2 stuck closed

422

143

P1276-12 SCB of VSense line

425

144

P1279-72 Relay Stuck Open Plausibility error

428

145

P0638-22

Throttle Actuator Control Range/Performance (Bank 1):

Throttle valve actuator permanent control deviation (signal

amplitude > maximum)

431

146

P1102-11

Throttle Actuator "A" Control Motor Circuit Low : Throttle

valve actuator output 2 circuit low

435

147

P1103-12

Throttle Actuator "A" Control Motor Circuit High : Throttle

valve actuator output 2 circuit high

439

148

P1118-16

Throttle Actuator "A" Control Motor Current

Range/Performance: Throttle valve actuator command

undervoltage

443
