Q501 4 Cylinder MT Application
DTC Troubleshooting Data
Version: 0.1
Date: 21-Sep-2018
Prepared By: Mithi Prasad, Sarang Kulkarni, Manish Gupta
Checked By: Yogesh Jadhav
Approved By: Satish Kumar P
Page: 1041 of 1052
Copyright © TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
22
Lost Communication With Anti-Lock Brake System (ABS)
Control Module: ABS/ESP Node Tout Faulty NO
23
Lost Communication With All Terrain Control Module: Drive
Control Switch / DCS Node Tout Faulty NO
24
Lost Communication With Body Control Module: BCM Node
Tout Faulty NO
25
Lost Communication With Restraints Control Module: SRS
Node Tout Faulty NO
26
Lost Communication With Instrument Panel Cluster (IPC)
Control Module: IPC Node Tout Faulty NO
27
Lost Communication With HVAC Control Module: CCM
Climate control Module Node Tout Faulty NO
28
Invalid Data Received From Instrument Panel Cluster Control
Module : IPC Node Invalid data faulty NO
29 NO
30
Cruise Control "On" Signal: Cruise ON/Off button stuck key
error NO
31
Brake booster pressure sensor circuit range / performance :
Cruise Cncl button stuck key error NO
32
Cruise Control "Resume" Signal: Cruise plus button stuck key
error NO
33
Brake Booster Pressure Sensor Circuit High : Cruise Minus
button stuck key error NO
34
Cruise Control Input Circuit Low: Diagnostic fault check for
SRC MIN error when analog key detection is enabled NO
35
Cruise Control Input Circuit High: Diagnostic fault check for
SRC MAX error when analog key detection is enabled NO
36
Cruise Control Multi-Function Input "A" Circuit
Range/Performance: NPL error NO
37 NO
38 NO
39 NO
40 NO
41 NO
42 NO
