Q501 4 Cylinder MT Application
DTC Troubleshooting Data
Version: 0.1
Date: 21-Sep-2018
Prepared By: Mithi Prasad, Sarang Kulkarni, Manish Gupta
Checked By: Yogesh Jadhav
Approved By: Satish Kumar P
Page: 1043 of 1052
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
74
P268C-55 IMA classification injector 1 missed personalizationNO
22375
P268C-56 check of IMA quantisation type mismatch injector 1NO
22576
P268D-55 IMA classification injector 2 missed personalizationNO
22777
P268D-56 check of IMA quantisation type mismatch injector 2NO
22978
P268E-55 IMA classification injector 3 missed personalizationNO
23179
P268E-56 check of IMA quantisation type mismatch injector 3NO
23380
P268F-55 IMA classification injector 4 missed personalizationNO
23581
P268F-56 check of IMA quantisation type mismatch injector 4NO
23782
P0513-86Incorrect Immobilizer Key: Bad ICU authentication
NO
23983
P0633-54Immobilizer Key Not Programmed - ECM/PCM :MCU blank
and free−starts exhausted
NO
24284
P1513-29 None plausible EEP values foundNO
24485
P3017-95 No valid key was detectedNO
24786
U1167-31 Frame VICM2 is absentNO
25087
P1D4C-04 Injection system monitoring (system internal failures)NO
25388
P1D45-49 Injection system monitoring (internal electronic failure)NO
25589
P0611-92 Fuel injector control module performanceNO
25790
P242C-11 Inlet Diesel Particulate Filter exhaust gas temperature sensor (circuit short to ground)NO
25991
P242D-15 Inlet Diesel Particulate Filter exhaust gas temperature sensor (circuit short to battery or open)NO
26292
P0251-13 Metering Unit electrical failure (open circuit)NO
26593
P0252-4B Metering Unit electrical failure (over temperature)NO
26894
P0253-11 Metering Unit electrical failure (circuit short to ground)NO
27195
P0031-11HO2S Heater Control circuit low: Lambda probe upstream
heater command signal low
NO
27496
P0032-12HO2S Heater Control circuit high: Lambda probe upstream
heater command signal high
NO
27897
P0053-1E Lambda sensor upstream heater diagnosis (circuit resistance out of range)NO
28298
P112A-21 Lambda sensor upstream signal plausibility check (signal amplitude < minimum)NO
28699
P112B-22 Lambda sensor upstream signal plausibility check (signal amplitude > maximum)NO
290100
P2243-13O2 sensor circuit: Lambda sensor wire diagnosis open load at
pin IPE, sensor 1 bank 1
NO
294101
P2626-13O2 sensor circuit: Lambda sensor wire diagnosis open load at
pin APE, sensor 1 bank 1
NO
298102
P0131-11O2 sensor circuit low voltage: Lambda sensor upstream wire
diagnosis (circuit short to ground)
NO
302
