Immobilizer –DTC Troubleshooting Data
Version: 1.
2
Date:
03-June-2014
Prepared Author
:
Sarang K/Mithipati P
Review & approved by
: R A Rode (ERC-E&E)
Page: 67 of 67
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
Annexure: DTC Table
Sr
No
DTC No
TML DTC Description
Page
No
Display
Status
(mask
status)
1
B163A-96
Vehicle immobilizer control module component internal failure
4
N
2
B163D-13
Lost Communication with antenna circuit open
6
N
3
B1636-31
Vehicle Immobilizer Control Module Communication with transponder No signal
8
N
4
B1636-81
Vehicle Immobilizer Control Module Communication with transponder- invalid
serial data received.
10
N
5
B1637-57
Vehicle Immobilizer Control Module Transponder invalid incomplete software
component
12
N
6
B1637-84
Vehicle Immobilizer Control Module Transponder signal below allowable range
14
N
7
B1639-06
Vehicle immobilizer control Module EMS-Immo handshake failed
16
N
8
B1639-81
Vehicle Immobilizer Control Module Invalid Data Received
18
N
9
B1639-31
Vehicle immobilizer control module no signal
20
N
10 U3000-08
Control Module - Bus Signal / Message Failures
22
Y
11 U1006-42
Control Module Internal- general memory failure
26
N
12 P0604-00
Internal Control Module Random Access Memory (RAM) Error
29
N
13 U3006-16
Control Module Input Power "A"- circuit voltage below threshold
32
N
14 U3006-17
Control Module Input Power "A"- circuit voltage above threshold
36
N
15 U3007-14
Control Module Input Power "A"- circuit voltage Circuit Short To Ground Or Open 40
N
16 U0028-13
Vehicle Communication Bus A-open circuit
45
N
17 U0028-88
Vehicle Communication Bus A-Bus off
49
N
18 U0100-08
Lost Communication with ECM (MTO) - Bus Signal / Message Failures
52
N
19 B163A-12
Vehicle immobilizer control module Status Indicator short to Ground or Open
Circuit
57
N
20 B163A-14
Vehicle immobilizer control module Status Indicator short to Ground or Open
Circuit
59
N
21 U1614-81
Odometer storage fault invalid serial data received
61
N
22 U1614-62
Odometer Storage Fault- Signal Compare Failure
63
N
23 U1614-94
Odometer Storage Fault- unexpected
65
N
24 U0100-08
Lost communication with ECM/PCM
--
Y
