Q501 4 Cylinder MT Application
DTC Troubleshooting Data
Version: 0.1
Date: 21-Sep-2018
Prepared By: Mithi Prasad, Sarang Kulkarni, Manish Gupta
Checked By: Yogesh Jadhav
Approved By: Satish Kumar P
Page: 1049 of 1052
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
220
P0182-11 Fuel Temperature Sensor “A” Circuit Low – Fuel temperature sensor (circuit short to ground)NO
722221
P0183-15 Fuel Temperature Sensor “A” Circuit High – Fuel temperature sensor (circuit short to battery or open)NO
726222
P0201-13 Injector Circuit/Open Cylinder 1 – Injector 1 command openNO
730223
P0202-13 Injector Circuit/Open Cylinder 2 – Injector 2 command openNO
733224
P0203-13 Injector Circuit/Open Cylinder 3 – Injector 3 command openNO
736225
P0204-13 Injector Circuit/Open Cylinder 4 – Injector 4 command openNO
739226
P0219-3A Engine Over speed Condition – Engine overspeed recognitionNO
742227
P242B-64 Exhaust Gas Temperature sensor Circuit Range / Performance Bank 1 Sensor 3 – Inlet Diesel Particulate Filter exhaust gas temperature sensor plausibilityNO
745228
P245A-13 EGR cooler bypass control Circuit / Open Bank 1 – EGR high pressure cooler bypass command (circuit open)NO
748229
P245B-4B EGR Cooler bypass control circuit range / performance – EGR high pressure cooler bypass command (over temperature)NO
752230
P245C-11 EGR cooler bypass control Circuit low Bank 1 – EGR high pressure cooler bypass command (circuit short to ground)NO
756231
P245D-12 EGR cooler bypass control Circuit High Bank 1 – EGR high pressure cooler bypass command (circuit short to battery)NO
760232
P246F-64 Exhaust Gas Temperature sensor Circuit Range / Performance Bank 1 Sensor 4 – Outlet Diesel Particulate Filter exhaust gas temperature sensor plausibilityNO
764233
P0261-11 Cylinder 1 Injector Circuit Low – Short circuit of the power stage low side (cylinder 1 error)NO
767234
P0262-2B Cylinder 1 Injector Circuit High – Short circuit between high side and low side of the power stage cylinder 1NO
770235
P263E-4B Glow Plug Control Module Command – Glow plug relay command (over temperature)NO
773236
P0264-11 Cylinder 2 Injector Circuit Low – Short circuit of the power stage low side (cylinder 2 error)NO
778237
P0266-2B Cylinder 2 Injector Circuit High – Short circuit between high side and low side of the power stage cylinder 2NO
781238
P0267-11 Cylinder 3 Injector Circuit Low – Short circuit of the power stage low side (cylinder 3 error)NO
784239
P0268-2B Cylinder 3 Injector Circuit High – Short circuit between high side and low side of the power stage cylinder 3NO
787240
P0270-11 Cylinder 4 Injector Circuit Low – Short circuit of the power stage low side (cylinder 4 error)NO
790241
P0271-2B Cylinder 4 Injector Circuit High – Short circuit between high side and low side of the power stage cylinder 4NO
793242
P0335-31 Crank Shaft Position Sensor “A” Circuit – Engine speed sensor general electrical failureNO
796
