Q501 4 Cylinder MT Application

DTC Troubleshooting Data

Version: 0.1

Date: 21-Sep-2018

Prepared By: Mithi Prasad, Sarang Kulkarni, Manish Gupta

Checked By: Yogesh Jadhav

Approved By: Satish Kumar P

Page: 1050 of 1052

Copyright ©

TATA MOTORS Ltd.

This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.

243

P0336-2F Crank Shaft Position Sensor “A” Circuit Range / Performance – crankshaft signal disturbance

NO

800

244

P0340-64 Camshaft Position Sensor “A” Circuit – Camshaft sensor signal invalid

NO

804

245

P0341-64 Camshaft Position Sensor “A” Circuit Range / Performance – Camshaft sensor general electrical failure

NO

808

246

P0383-11 Glow Plug Control Module 1 Control Circuit Low – Glow plug relay command (circuit short to ground)

NO

812

247

P0384-12 Glow Plug Control Module 1 Control Circuit High – Glow plug relay command (circuit short to battery)

NO

816

248

P0401-21 EGR “A” Flow Insufficient Detected – The minimum control deviation falls below the lower limit

NO

821

249

P0402-22 EGR “A” Flow Excessive Detected – The maximum control deviation exceeds the upper limit

NO

825

250

P0403-13 EGR “A” Control Position Circuit Open – EGR high pressure valve control open

NO

829

251

P0404-19 EGR “A” Control Circuit Range / Performance – EGR high pressure valve control (circuit current above threshold)

NO

833

252

P0405-14 EGR Sensor “A” Circuit Low – EGR high pressure valve position sensor electrical test (circuit short to ground or open)

NO

837

253

P0406-12 EGR Sensor “A” Circuit High – EGR high pressure valve position sensor electrical test (circuit short to battery)

NO

841

254

P0409-78 EGR Sensor “A” Circuit – EGR high pressure valve position sensor (functional test, alignment or adjustment incorrect)

NO

845

255

P0480-13 Fan1 Control Circuit – Cooling Fan 1 (open circuit)

NO

849

256

P0481-13 Fan2 Control Circuit – Cooling Fan 2 (open circuit)

NO

852

257

P0484-4B Fan Circuit current High – Cooling Fan 1 (over temperature)

NO

855

258

P0489-11 Exhaust Gas Re-circulation “A” Control Circuit High – EGR high pressure valve control out 1 (circuit short to ground)

NO

858

259

P0490-12 Exhaust Gas Re-circulation Control Circuit High – EGR high pressure valve control out 1 (circuit short to battery)

NO

863

260

P0562-16 System Voltage Low – Upstream main relay battery voltage below threshold

NO

867

261

P0563-17 System Voltage High – Upstream main relay battery voltage above threshold

NO

870

262

P0571-94 Brake Switch “A” Circuit – Brake pedal switch signal incorrect after event (0/1 error)

NO

873

263

P0601-44 Internal Control Module Memory checksum error – Error state of EEPROM (data memory failure)

NO

878

264

P0602-45 Internal Control Module Read only Memory (ROM) error – Error state of EEPROM (program memory failure)

NO

880

265

P0645-13 A/C Clutch Relay Control Circuit – AC compressor (open load)

NO

882

266

P0646-11 A/C Clutch Relay Control Circuit Low – AC compressor (Short circuit to ground)

NO

885
