TRANSMISSION
48
52. Remove the support transmission jack.
53. If a new transmission is installed, no need to
follow the steps below, go to point 51.
54. Perform the fluid level. See Transmission Oil
Level after repairs procedure.
55. Program the transmission module.
56. Enter the VIN into the transmission module
using the diagnostic tool.
57. Clear any fault codes generated by the
programming / replacing operation.
58. Road test the vehicle and release to
customer.
Torque Converter Removing Procedure:
1. Drain the transmission. See Fluid Drain and
Oil Pan Removing Procedure.
2. Remove the transmission from vehicle.
CAUTION:
The transmission must remain in horizontal
position to avoid converter to fall down.
3. Install the transmission on Hanger of Lifting
Gear Box (287058902616).
4. Pull & remove the Torque Converter.
