TRANSMISSION
46
36. Install the rear propeller shaft on the transfer
box.
37. Tighten the 2 support propeller shaft screws
to 1.8Kg-m to 2.2Kg-m
38. Using a H9 wrench, turn the selector shaft out
of park to allow propeller shaft turning and
access to the other propeller shaft screws.
39. Tighten the 2 remaining support propeller
shaft screws to 1.8 kg-m to 2.2Kg-m.
40. Install the front propeller shaft on the transfer
box.
41. Tighten the 4 support propeller shaft screws
to1.8 to 2.2Kg-m.
42. Connect the transfer box connector.
43. Install the catalyst at the front, tighten to 3.5
Kg-m
44. Install the middle exhaust system, tighten to
3.5 Kg-m.
