GEAR BOX

23

10.Remove the gasket which is between rear half

and rear cover

.(For 4X2 Version only)

NOTE

For 4X4 Version (If Applicable)

Remove the gasket which is between rear half and

adaptor.

11.Mount the gearbox assembly on to the mounting

stand such that drive shaft end face is in upward

direction.

12.Loosen and remove the breather assembly.
