HEXA

GEAR BOX

18. Remove shims and take out the gasket.

19.Loosen and remove the mounting screw which is

for reverse idler shaft in the front housing. Also

take out the spring and bright washer along with

the screw.

20. Loosen and remove nuts of front half housing.

21.Separate front half from rear half.

NOTE

If required pull the front half with the help of puller

(Part No. 2654 5890 26 09).
