1774 / 1906
BODY
39
IX.
DOOR LATCH REAR:
REMOVAL:
SR.
NO.
DESCRIPTION
1
Inner handle (Rear Door)
2
Pop knob upper
3
Cable pop knob lower to latch
4
Cable inner handle to latch
5
Link between outer handle to latch
6
Outer door handle bracket
7
Latch
1. Remove the door trim.
(For procedure refer
door trim removal procedure.)
2. Remove rear door outer handle.
(For
procedure refer outer door lock (Rear) removal
process.)
3. Disconnect electrical connector at the latch
end.
4. Push the pop knob to downward position so as
to have in lock position to have better access
to remove the links.
5. Disconnect the inner handle cable from the
inner door handle and bracket.
6. Disconnect pop knob lower cable from the
bracket.
7. Disconnect outer handle link from the handle
end.
