43

3. Loosen and remove two mounting bolts and

take out the tail gate actuator assembly along

with the mounting bracket.

4. Disconnect the electrical connection from the

tail gate actuator.

5. Loosen and remove three mounting screws

and separate the actuator assembly from the

bracket.

FITMENT

For fitment follow reverse procedure of removal.

V. TAILGATE TRIM

REMOVAL:

1. Open the tail gate.

2. Remove cap of door pull handle of the tail gate

assembly.

3. Loosen and remove one mounting screw and

take out the door pull handle of the tail gate

assembly.
