45

VII. SPOILER

1. Remove

the

spoiler by unsnapping the clips.

ASSEMBLY:

Assemble the spoiler by pressing.

I. MIRROR

I.

ORVM

REMOVAL:

1. Remove the door trim.

(For procedure refer

door

trim

removal procedure.)

2.

Pull

out the grommet to access the nut.

3.

Remove

three mounting nuts from the door

shell.

4. Take

out

the OVRM from the door shell.
