REAR AXLE
19
8. Take out the brake assembly from axle shaft.
9. Put the bearing holder on the bottom locator
install bearing removal
adaptor (Part No.
287058903506)
and press down the bearing to
remove from the bearing holder.
NOTE
The force of 700Kgf to 1500Kgf is required for
removal and fitment of bearing from bearing
holder.
It is recommended not to use bearing once
removed from axle shaft and if grease is
spilling out from bearing.
ASSEMBLY
CAUTION
The use of non-original equipment for
replacement of a part is not recommended as
their use may cause unit Failure and/ or affect
vehicle safety.
1. Place the bearing housing on base plate,
install the bearing and bearing pressing dolly
(Part No. 287058903507)
and press down the
bearing into bearing housing.
2. Install the bearing housing on the brake
assembly. Pull up the brake assembly bolt
through bearing housing flange hole and put
the nut on it and tighten it by hand.
