REAR AXLE
14
8. Make sure that rear axle assembly is properly
supported from below, then loosen and
remove the mounting bolt of pan hard rod,
follow the same procedure at the other end
also.
9. Loosen and remove the mounting bolts of
lower link assembly and separate the link from
the vehicle, follow the same procedure at the
other end also.
10.Loosen and remove the lower mounting nut of
the rear shock absorber.
11.Loosen and remove two mounting bolts from
the top.
12.Tap gently and take out the shock absorber
from the lower end to disconnect from the rear
axle and remove the Shock absorber.
13.Lift the vehicle upward through two post lift as
rear axle is now free from the vehicle and take
out the coil spring.
FITMENT
For fitment follow reverse procedure of removal.
