SAFARI

4 DLT ENGINE

Loosen power steering pump mounting bolt

adjuster bracket

. Fig.16

Loosen locknut

& then loosen adjuster hex. nut

till the belt can be removed.

Remove the belt.

Remove power steering mounting bolts & take out

power steering pump assembly. Fig.17

Remove the fan pulley using the puller. Fig.18

Unlock toggle clamps. Remove front clip holding front

timing gear train covers. Fig. 19

Remove all three (front right, front left, and front lower)

timing gear train covers.

Fig. 17

Fig. 18

Fig. 19

Fig. 16
