4 DLT ENGINE
Take out exhaust manifold by loosening nuts. Refer
figure 31.
R
emove inlet manifold by loosening allen screw by
allen key.
U
sing spanner, 2654 5890 05 01 lock camshaft gear.
Refer figure 32.
U
nscrew and remove camshaft gear mounting screw
with spacer.
R
emove camshaft gear and woodruff key.
R
emove belt tensioner locking screw and timing gear
train rear cover mounting screw at cylinder head. Refer
figure 33.
R
emove cylinder head cover. Refer figure 34.
Fig. 32
Fig. 33
Fig. 34
Fig. 31
