13.Remove music system (If applicable). (For
procedure refer music system removal process
in Electrical section).
14.Remove floor console assembly. (For
procedure refer floor console removal
process).
15.Remove PAB Assembly (If applicable). (For
procedure refer PAB removal process in SRS
section).
16.Remove A-pillar upper trim on LH and RH
side. (For procedure refer A pillar trim removal
process.)
17.Remove all electrical connections.
18.Remove front doors. (For procedure refer front
door removal process).
19.Remove two dashboard mounting bolts on LH
side as shown in figure.
20.Similarly remove two mounting bolts on RH
side.
21.Remove Dashboard mounting screw below
cluster location.
