ELECTRICAL
40
CONNECTIONS DETAILS
For circuit details refer circuit schematic section
CONDITION
POSSIBLE CAUSES
CORRECTION/REFERENCE ITEM
Horn not working
1. Grounding point loose
Tighten grounding properly
2. Horn fuse (15A) in Engine fuse box
blown
Replace the fuse
3. Horn relay in Engine loose
Fix the relay properly
4. Horn switch terminal / horn switch
contact in steering pad improper
Replace control switch plunger
topping/Adjust horn switch contact in
steering pad properly
Horn
sound
distorted
1. Horn terminals loose
Connect the terminals properly
2. Horn setting screw disturbed
Adjust the setting screw till a clean and
sharp sound is obtained
